经颅直流电刺激对意识障碍患者脑功能网络方向性连接的影响

doi:10.3969/j.issn.1006-9771.2025.09.008

Abstract

Abstract:

Objective To investigate the modulatory effects of transcranial direct current stimulation (tDCS) on directional information flow within the α-band functional brain networks in patients with disorders of consciousness (DoC).

Methods From October, 2023 to October, 2024, 30 patients with DoC were recruited from Binzhou Medical University Hospital. They were assigned to minimally conscious state (MCS) group (n = 15) and unresponsive wakefulness syndrome (UWS) group (n = 15). All the patients received conventional rehabilitation and tDCS at left dorsolateral prefrontal cortex for four weeks. Ten-minute electroencephalography data were collected before and after treatment.

Results Two cases dropped out from MCS group. Granger causality (GC) connectivity between the prefrontal and parietal regions enhanced in both groups after treatment, particularly in bidirectional pathways between bilateral prefrontal and parietal regions, as well as between frontocentral and parietal regions, and limbic-central connections. GC connectivity was extensive and bidirectional in MCS group, and localized and unidirectional in UWS group.

Conclusion tDCS can enhance directional information flow between bilateral prefrontal and parietal regions in patients with DoC, for promoting recovery of consciousness. Neural plasticity was better in MCS patients than in UWS patients.

Key words: disorders of consciousness, transcranial direct current stimulation, electroencephalography, Granger causality analysis

CLC Number:

R741.041

LI Hongwei, HUANG Binbin, ZHU Chuanhua, LI Wei. Effect of transcranial direct current stimulation on α-band brain connectivity in disorders of consciousness[J]. Chinese Journal of Rehabilitation Theory and Practice, 2025, 31(9): 1050-1056.

Figures/Tables 5

Table 1

Figure 1

Figure 2

Figure 3

Figure 4

References 41

[1]	TINTI L, LAWSON T, MOLTENI E, et al. Research considerations for prospective studies of patients with coma and disorders of consciousness[J]. Brain Commun, 2024, 6(1): fcad022.
[2]	HUANG W, CHEN Q, LIU J, et al. Transcranial magnetic stimulation in disorders of consciousness: an update and perspectives[J]. Aging Dis, 2023, 14(4): 1171-1183.
[3]	中国医师协会神经修复专业委员会意识障碍与促醒学组. 慢性意识障碍诊断与治疗中国专家共识[J]. 中华神经医学杂志, 2020, 19(10): 977-982.
	Group of Disorders of Consciousness and Conscious Promotion, Professional Committee of Neurorepair, Chinese Medical Doctor Association. Diagnoses and treatments of prolonged disorders of consciousness: an experts consensus[J]. Chin J Neuromed, 2020, 19(10): 977-982.
[4]	何晨, 宋明, 徐珑. 慢性意识障碍神经调控治疗进展[J]. 中国现代神经疾病杂志, 2025, 25(1): 48-56. doi: 10.3969/j.issn.1672-6731.2025.01.007
	HE C, SONG M, XU L. Advances in neuromodulation for treatment of prolonged disorders of consciousness[J]. Chin J Contemp Neurol Neurosurg, 2025, 25(1): 48-56. doi: 10.3969/j.issn.1672-6731.2025.01.007
[5]	BERNAL-JIMÉNEZ J J, DILEONE M, MORDILLO-MATEOS L, et al. Combining transcranial direct current stimulation with hand robotic rehabilitation in chronic stroke patients: a double-blind randomized clinical trial[J]. Am J Phys Med Rehabil, 2024, 103(10): 875-882.
[6]	FAN W, FAN Y, LIAO Z, et al. Effect of transcranial direct current stimulation on patients with disorders of consciousness: a systematic review and meta-analysis[J]. Am J Phys Med Rehabil, 2023, 102(12): 1102-1110.
[7]	LIU S, GAO Q, GUAN M, et al. Effectiveness of transcranial direct current stimulation over dorsolateral prefrontal cortex in patients with prolonged disorders of consciousness: a systematic review and meta-analysis[J]. Front Neurol, 2022, 13: 998953.
[8]	GANGEMI A, DE LUCA R, FABIO R A, et al. Cognitive effects of transcranial direct current stimulation plus robotic verticalization in minimally conscious state[J]. Biomedicines, 2024, 12(10): 2244.
[9]	LEE Y S, SHIM M, CHOI G Y, et al. Neuromodulatory feasibility of a current limiter-based tDCS device: a resting-state electroencephalography study[J]. Biomed Eng Lett, 2023, 13(3): 407-415.
[10]	KIM P J, KIM H T, CHOI B, et al. Graph approaches for analysis of brain connectivity during dexmedetomidine sedation[J]. Neurosci Lett, 2023, 797: 137060.
[11]	MAJDI A, ASAMOAH B, MCLAUGHLIN M. Understanding novel neuromodulation pathways in tDCS: brain stem recordings in rats during trigeminal nerve direct current stimulation[J]. Transl Psychiatry, 2024, 14(1): 456.
[12]	JAEGER C, NUTTALL R, ZIMMERMANN J, et al. Targeted rhythmic visual stimulation at individual participants' intrinsic alpha frequency causes selective increase of occipitoparietal BOLD-fMRI and EEG functional connectivity[J]. Neuroimage, 2023, 270: 119981.
[13]	CHEN J, SHI Y, DONG Z, et al. Research hotspots and trends in the application of electroencephalography for assessment of disorders of consciousness: a bibliometric analysis[J]. Front Neurol, 2025, 15: 1501947.
[14]	CARNEIRO T, GOSWAMI S, SMITH C N, et al. Prolonged monitoring of brain electrical activity in the intensive care unit[J]. Neurol Clin, 2025, 43(1): 31-50. doi: 10.1016/j.ncl.2024.08.001 pmid: 39547740
[15]	GUO Y, CAO B, HE Y, et al. Disrupted multi-scale topological organization of directed functional brain networks in patients with disorders of consciousness[J]. Brain Commun, 2023, 5(2): fcad069.
[16]	TROYAS C, OSTERTAG J, SCHNEIDER G, et al. Changes in intra- and cross-hemispheric directed functional connectivity in the electroencephalographic signals during propofol-induced loss of consciousness[J]. Anesthesiology, 2025, 142(1): 142-154.
[17]	CHEN Z, JI X, LI T, et al. Lateralization difference in functional activity during Stroop tasks: a functional near-infrared spectroscopy and EEG simultaneous study[J]. Front Psychiatry, 2023, 14: 1221381.
[18]	ZHANG S, CUI H, LI Y, et al. Improving SSVEP-BCI performance through repetitive anodal tDCS-based neuromodulation: insights from fractal EEG and brain functional connectivity[J]. IEEE Trans Neural Syst Rehabil Eng, 2024, 32: 1647-1656.
[19]	中国残疾人康复协会,中国康复医学会,中国康复研究中心. 慢性意识障碍康复中国专家共识[J]. 中国康复理论与实践, 2023, 29(2): 125-139. doi: 10.3969/j.issn.1006-9771.2023.02.001
	China Association of Rehabilitation of Disabled Persons, China Association of Rehabilitation Medicine, China Rehabilitation Research Center. China expert consensus on rehabilitation of prolonged disorders of consciousness[J]. Chin J Rehabil Theory Pract, 2023, 29(2): 125-139.
[20]	GRABARCZYK L. Assessment of the potential of modern diagnostic tools in differentiation of minimum conscious state from the vegetative state[J]. Ann Neurosci, 2024, 26: 09727531241254214.
[21]	BODIEN Y G, VORA I, BARRA A, et al. Feasibility and validity of the Coma Recovery Scale-Revised for accelerated standardized testing: a practical assessment tool for detecting consciousness in the intensive care unit[J]. Ann Neurol, 2023, 94(5): 919-924. doi: 10.1002/ana.26740 pmid: 37488068
[22]	WOODS A J, ANTAL A, BIBSON M, et al. A technical guide to tDCS, and related non-invasive brain stimulation tools[J]. Clin Neurophysiol, 2016, 127(2): 1031-1048. doi: S1388-2457(15)01088-3 pmid: 26652115
[23]	JOG M A, ANDERSON C, KUBICKI A, et al. Transcranial direct current stimulation (tDCS) in depression induces structural plasticity[J]. Sci Rep, 2023, 13(1): 2841. doi: 10.1038/s41598-023-29792-6 pmid: 36801903
[24]	TARANTINO V, FONTANA M L, BUTTÀ A, et al. Increase in EEG alpha-to-theta ratio after transcranial direct current stimulation (tDCS) in patients with disorders of consciousness: a pilot study[J]. NeuroRehabilitation, 2024, 55(4): 440-447.
[25]	LI K, LUO X, ZENG Q, et al. Gray matter structural covariance networks patterns associated with autopsy-confirmed LATE-NC compared to Alzheimer's disease pathology[J]. Neurobiol Dis, 2023, 189: 106354.
[26]	KHAN A, ANTONAKAKIS M, SUNTRUP-KRUEGER S, et al. Can individually targeted and optimized multi-channel tDCS outperform standard bipolar tDCS in stimulating the primary somatosensory cortex?[J]. Brain Stimul, 2023, 16(1): 1-16.
[27]	BARRA A, HUERTA-GUTIERREZ R, ANNEN J, et al. Characterization of responders to transcranial direct current stimulation in disorders of consciousness: a retrospective study of 8 clinical trials[J]. Neurotherapeutics, 2025: e00587.
[28]	JIN X, LIANG Z, WEN X, et al. The characteristics of electroencephalogram signatures in minimally conscious state patients induced by general anesthesia[J]. IEEE Trans Biomed Eng, 2023, 70(11): 3239-3247.
[29]	FURUKAWA R, KUME K, TATENO T. Analyzing the transient response dynamics of long-term depression in the mouse auditory cortex in vitro through multielectrode-array-based spatiotemporal recordings[J]. Front Neurosci, 2024, 18: 1448365.
[30]	CHEN C, HAN J, ZHENG S, et al. Dynamic changes of brain activity in different responsive groups of patients with prolonged disorders of consciousness[J]. Brain Sci, 2022, 13(1): 5.
[31]	LI S, HE Y, TURNER D, et al. Electrophysiological phenotypes of hippocampal synaptic and network functions in cannabinoid receptor 2 knockout mice[J]. Cannabis Cannabinoid Res, 2024, 9(5): 1267-1276.
[32]	OLGIATI E, VIOLANTE I R, XU S, et al. Targeted non-invasive brain stimulation boosts attention and modulates contralesional brain networks following right hemisphere stroke[J]. Neuroimage Clin, 2024, 42: 103599.
[33]	MISSELHORN J, FIENE M, RADECKE J O, et al. Transcranial alternating current stimulation over frontal eye fields mimics attentional modulation of visual processing[J]. J Neurosci, 2024, 44(25): e1510232024.
[34]	ZIOGA I, KENETT Y N, GIANNOPOULOS A, et al. The role of alpha oscillations in free- and goal-directed semantic associations[J]. Hum Brain Mapp, 2024, 45(10): e26770.
[35]	LUCHINI S A, ZHANG X, WHITE R T, et al. Enhancing creativity with covert neurofeedback: causal evidence for default-executive network coupling in creative thinking[J]. Cereb Cortex, 2025, 35(4): bhaf065.
[36]	STEIN J, KORB F M, GOSCHKE T, et al. Salience network resting-state functional connectivity predicts self-controlled decision-making[J]. Sci Rep, 2025, 15(1): 16332.
[37]	WHEELOCK M D, STRAIN J F, MANSFIELD P, et al. Brain network decoupling with increased serum neurofilament and reduced cognitive function in Alzheimer's disease[J]. Brain, 2023, 146(7): 2928-2943. doi: 10.1093/brain/awac498 pmid: 36625756
[38]	BAI Y, YANG L, MENG X, et al. Breakdown of effective information flow in disorders of consciousness: insights from TMS-EEG[J]. Brain Stimul, 2024, 17(3): 533-542. doi: 10.1016/j.brs.2024.04.011 pmid: 38641169
[39]	PANDA R, THIBAUT A, LOPEZ-GONZALEZ A, et al. Disruption in structural-functional network repertoire and time-resolved subcortical fronto-temporoparietal connectivity in disorders of consciousness[J]. eLife, 2022, 11: e77462.
[40]	BANWINKLER M, THEIS H, PRANGE S, et al. Imaging the limbic system in Parkinson's disease: a review of limbic pathology and clinical symptoms[J]. Brain Sci, 2022, 12(9): 1248.
[41]	ZHU C, FU Z, CHEN L, et al. Multi-modality connectome-based predictive modeling of individualized compulsions in obsessive-compulsive disorder[J]. J Affect Disord, 2022, 311: 595-603.

组别	n	性别(男/女)/n	年龄/岁	病程/d
MCS组	13	10/3	59.46±8.64	45.38±12.81
UWS组	15	9/6	54.00±11.83	51.33±15.77
χ²/t值		0.914	1.376	-1.084
P值		0.435	0.431	0.288
